PC817 2 Channel Optocoupler Isolation Module
This module is helpful in connecting digital systems (eg 5V microcontrollers) to a high-voltage system. The board electrically isolates the controller from the high-efficiency circuit by means of an optical-isolation IC. The IC has built-in two LEDs and two photodiodes. This allows the low voltage side to control the high voltage side.
Technical Specification:
- No. of Channels: 2
- Input Voltage: 3.6-24 VDC
- Output Voltage: 3.6-30 V
- Size: 38m*29mm*12mm (L*W*H)
Ā Features:
- Output Can Be Switched From Pull-Up or Pull-Down With Jumpers
- This breakout board helps to add opto isolation to any circuit with minimum amount of wiring
Ā Applications:Ā Ā Ā Ā Ā Ā Ā Ā Ā
- Computer terminals
- System appliances, measuring instruments
- Registers, copiers, automatic vending machines
- Electric home appliances
